How to map a fly brain in 20 million easy steps

By analysing the connectome of just a small part of the fly brain the team identified dozens of new neuron types and pinpointed neural circuits that appear to help flies make their way through the world.

Drosophila melanogasterDrosophila melanogaster (Wikimedia Commons)

Written by Emily Anthes

The brain of a fruit fly is the size of a poppy seed and about as easy to overlook.

“Most people, I think, don’t even think of the fly as having a brain,” said Vivek Jayaraman, a neuroscientist at the Janelia Research Campus of the Howard Hughes Medical Institute in Virginia. “But, of course, flies lead quite rich lives.”

Flies are capable of sophisticated behaviors. And their specksize brains are tremendously complex, containing about 100,000 neurons and tens of millions of connections, or synapses, between them.

Since 2014, a team of scientists at Janelia, in collaboration with researchers at Google, have been mapping these neurons and synapses in an effort to create a comprehensive wiring diagram, also known as a connectome, of the fruit fly brain.

The work is time-consuming and expensive, even with the help of state-of-the-art machine-learning algorithms. But the data they have released so far is stunning in its detail, composing an atlas of gnarled neurons in many crucial areas of the fly brain.

And now, in a new paper being published Tuesday in the journal eLife, neuroscientists are beginning to show what they can do with it.

By analysing the connectome of just a small part of the fly brain — the central complex, which plays an important role in navigation — Jayaraman and his colleagues identified dozens of new neuron types and pinpointed neural circuits that appear to help flies make their way through the world. The work could help provide insight into how all kinds of animal brains, including our own, process a flood of sensory information and translate it into appropriate action.


It is also a proof of principle for the young field of modern connectomics, which was built on the promise that constructing detailed diagrams of the brain’s wiring would pay scientific dividends.

“It’s really extraordinary,” Dr. Clay Reid, a senior investigator at the Allen Institute for Brain Science in Seattle, said of the new paper. “I think anyone who looks at it will say connectomics is a tool that we need in neuroscience — full stop.”

The only complete connectome in the animal kingdom belongs to the humble roundworm, C. elegans. Biologist Sydney Brenner, who would later go on to win a Nobel Prize, started the project in the 1960s. His small team spent years on it, using colored pens to trace all 302 neurons by hand.


When the Janelia Research Campus opened in 2006, Gerald Rubin, its founding director, set his sights on the fruit fly.

Several different teams at Janelia have embarked on fly connectome projects in the years since, but the work that led to the new paper began in 2014, with the brain of a single, 5-day-old female fruit fly.

Researchers cut the fly brain into slabs and then used a technique known as focused-ion beam scanning electron microscopy to image them, layer by painstaking layer. The microscope essentially functioned like a tiny, precise nail file, filing away an exceedingly thin layer of the brain, snapping a picture of the exposed tissue and then repeating the process until nothing remained.

“You’re simultaneously imaging and cutting off little slices of the fly brain, so they don’t exist after you’re done,” Jayaraman said.

The team then used computer vision software to stitch the millions of resulting images back together into a single, 3D volume and sent it off to Google. There, researchers used advanced machine-learning algorithms to identify each individual neuron and trace its twisting branches.


Finally, the Janelia team used additional computational tools to pinpoint the synapses, and human researchers proofread the computers’ work, correcting errors and refining the wiring diagrams.

Last year, the researchers published the connectome for what they called the “hemibrain,” a large portion of the central fly brain, which includes regions and structures that are crucial for sleep, learning and navigation.


The connectome, which is accessible free online, includes about 25,000 neurons and 20 million synapses, far more than the C. elegans connectome.

“It’s a dramatic scaling up,” said Cori Bargmann, a neuroscientist at Rockefeller University in New York. “This is a tremendous step toward the goal of working out the connectivity of the brain.”


Once the hemibrain connectome was ready, Jayaraman, an expert on the neuroscience of fly navigation, was eager to dive into the data on the central complex.

The brain region, which contains nearly 3,000 neurons and is present in all insects, helps flies build an internal model of their spatial relationship to the world and then select and execute behaviors appropriate for their circumstances, such as searching for food.

“You’re telling me you can give me the wiring diagram for something like this?” Jayaraman said. “This is better industrial espionage than you could get by getting insights into the Apple iPhone.”

The researchers hypothesise that fly brains may be wired to prioritize information about the global environment when they are navigating, but also that these circuits are flexible, so that when such information is inadequate, they can pay more attention to local features of the landscape.

Other members of the research team identified specific neural pathways that seem well suited to helping the fly keep track of its head and body orientation; anticipate its future orientation and traveling direction; calculate its current orientation relative to another desired location; and then move in that direction.

Imagine, for instance, that a hungry fly temporarily abandons a rotting banana to see whether it can rustle up something better. But after a (literally) fruitless few minutes of exploration, it wants to return to its previous meal.

The connectome data suggests that certain brain cells, technically known as PFL3 neurons, help the fly pull off this maneuver. These neurons receive two critical inputs: They get signals from neurons that track the direction the fly is facing as well as from neurons that may be keeping tabs on the direction of the banana.

After receiving those signals, the PFL3 neurons then send out their own message to a set of turning neurons that prompt the fly to veer off in the correct direction. Dinner is served, again.

“Being able to trace that activity through that circuit — from sensory back to motor through this complex intermediate circuit — is really amazing,” said Brad Hulse, a research scientist in Jayaraman’s lab who led this part of the analysis. The connectome, he added, “showed us a lot more than we thought it was going to.”

And the group’s paper, a draft of which includes 75 figures and stretches to 360 pages, is just the beginning.

“It just really provides this ground truth for exploring this brain region further,” said Stanley Heinze, an expert on insect neuroscience at Lund University in Sweden. “It’s just enormously impressive.”

One could have asked — some did — why a fruit fly’s brain circuitry matters.

“I get asked this at the holidays a lot,” Hulse said.

Flies are not mice or chimps or humans, but their brains perform some of the same basic tasks. Understanding the basic neural circuitry in an insect could provide important clues to how other animal brains approach similar problems, said David Van Essen, a neuroscientist at Washington University in St. Louis.

Gaining a deep understanding of the fly’s brain “also gives us insights that are very relevant to the understanding of mammalian, and even human, brains and behavior,” he said.

Creating connectomes of larger, more complex brains will be enormously challenging. The mouse brain contains roughly 70 million neurons, the human brain a whopping 86 billion.

But the central complex paper is decidedly not a one-off; detailed studies of regional mouse and human connectomes are in the pipeline, Reid said: “There’s a lot more to come.”

Journal editors, consider yourselves warned.
