Prosthetic foot designed for disabled women to wear heels
Prominence allows women with amputated lower limbs to regain a part of modern femininity.
Prominence, the base for the prosthetic foot, was made from a 28-layer fibre carbon foot plate. (Source: Thinkstock Images)
A team of students has developed an early version of a foot that enables women adjusting to life with a prosthetic limb to wear heels up to four inches high.
“High heels have become an integral part of the female lifestyle in modern society, permeating through all aspects of life – professional and social,” said the authors from Johns Hopkins University who made the prosthetic foot as part of their final senior year project in mechanical engineering.
Read More
- Study confirms cardiovascular benefits of semaglutide drug beyond weight loss
- At 95, he had body of 75: Why this fit group qualifies for procedures done on people in their 70s
- Why US plans to drop millions of flies from planes
- 3 doctors recount how patients surprised them by challenging therapies
- When autism is a greater ability than disability: Bengaluru boy runs YouTube music channel. All he needed was encouragement
“For female veterans of the US armed services with lower limb amputations, that seemingly innocuous but so pervasive and decidedly feminine part of their lives is gone,” they added.
So, they took up the challenge of creating a foot that adjusts without a separate tool to a range of heel heights, holds position without slipping, supports up to 114kg, weighs less than 1.3kg and, of course, is slender enough to accommodate a woman’s shoe.
They tried a balloon in the heel to give it spring or ‘energy return’, as engineers say. But that didn’t work. They tried a mousetrap spring but that didn’t work either. Then, they tried a sideways sandwich of 23 slender titanium plates to form the foot itself but that was too heavy and not springy. A 20-layer carbon fibre foot plate failed a stress test, but a 28-layer version worked, forming the base of the foot which the team now calls the ‘Prominence’.
They built a heel adjustment mechanism with two interlocking aluminium disks. It opens and closes with an attached lever at the ankle. For the ankle, they used an off-the-shelf hydraulic unit that enables a smooth gait and flexing at the sole.
Alexandra Capellini, a Johns Hopkins University junior who lost her right leg to bone cancer as a child, tried the foot with a flat shoe and liked it.
The design is still in progress. It will take some time to assess the commercial appeal and potential of the ‘Prominence’, including the question of whether anything the team created could qualify for a patent.
